Our presswork facilities range from 12 to 400 tons, both mechanical and hydraulic metal pressing operations with associated feed equipment. We are specialists in technically challenging high volume presswork for the following industries. Automotive, Defence, Aerospace, Electronics, Metal Packaging, Public Utilities, Heating and Ventilation markets.
Hydraulic Presses
| Make | Model | Tonnage | Stroke (mm) | Bed Size (mm) | Shut Height (mm) | Quantity |
|---|---|---|---|---|---|---|
| Tranemo | D/S Large Bed | 315 | 800 | 2500 x 1300 | 200 min | 1 |
| Tranemo | D/S Large Bed | 315 | 800 | 1900 x 1300 | 200 min | 1 |
| Hare | H.P. 63 | 63 | 150 Max | 900 x 580 | 350 min | 4 |
| Hare | H.P. 25 | 25 | 150 Max | 650 x 480 | 300 min | 3 |
| Hare | H.P. 16 | 16 | 150 Max | 650 x 480 | 300 min | 2 |
| Hare | G.P. 10 | 10 | 125 Max | 500 x 380 | 200 min | 1 |
Mechanical Presses
Tool Protection Systems fitted to High Tonnage Presses
| Make | Model | Tonnage | Stroke (mm) | Bed Size (mm) | Shut Height (mm) | Quantity |
|---|---|---|---|---|---|---|
| Rhodes | DS 2 | 400 | 50-200 | 1525 x 1220 | 482 | 1 |
| Stanko | 250T H Frame | 250 | 400 | 2500 x 1250 | 580 | 1 |
| Stanko | 160 H Frame | 160 | 200 | 2000 x 1250 | 490 | 2 |
| Stanko | 160 H Frame | 160 | 25-160 | 1000 x 670 | 290 | 1 |
| Make | Model | Tonnage | Stroke (mm) | Bed Size (mm) | Shut Height (mm) | Quantity |
|---|---|---|---|---|---|---|
| Aida | NC2 160 Transfer | 160 | 200 | 2040 x 760 | 450 min | 1 |
| Edelhoff | Darr 1/130 | 130 | 20-130 | 1010 x 860 | 370 | 1 |
| Aida | NC1 110 | 110 | 180 | 1070 x 680 | 350 | 1 |
| Aida | NC1 80 | 80 | 160 | 950 x 600 | 320 | 1 |
| HME | AH 80 Bentley | 80 | 25-127 | 890 x 610 | 350 | 1 |
| HME | GH 75 | 75 | 25-127 | 900 x 570 | 350 | 1 |
| Aida | NC1 60 | 60 | 55 | 870 x 400 | 270 | 1 |
| HME | GH 40 | 40 | 25-101 | 700 x 480 | 260 | 2 |
| HME | GH 40 | 40 | 25-101 | 700 x 480 | 260 | 1 |
| HME | OH 40 | 40 | 25-101 | 700 x 480 | 260 | 1 |
| MABU | 25 VPR | 25 | 7-62 | 400 x 330 | 310 | 1 |
| HME | GP 20 | 20 | 19-88 | 560 x 360 | 220 | 1 |
| HME | G 12 | 12 | 12.7-76 | 480 x 320 | 196 | 1 |
